Hollow Pin Conveyor Chains (FVC Series) for Custom Attachments | Donghua

Donghua's hollow pin conveyor chains (FVC Series) are engineered to solve one of the most common challenges in custom conveying: the need to mount attachments, flights, or specialized tooling directly to the chain. The hollow pin design provides a clean, secure attachment point, allowing you to build the exact conveying solution your application demands. As a leading global chain manufacturer since 1991, our FVC series chains are precision-engineered for reliability and flexibility.

Hollow Pin Technology: How It Enables Custom Conveying

Unlike standard roller chains, hollow pin chains feature pins that are tubular rather than solid. This design offers a distinct advantage: the hollow pin creates a perfect mounting point for custom attachments, flights, or crossbars. Key technical features include:

Attachment Versatility: Easily integrate custom fixtures, pushers, carriers, or sensors directly into the chain.
Standard Compatibility: Built on ISO 606 roller chain dimensions, so they are compatible with standard sprockets.
Pair-Matched for Precision: For applications requiring parallel running (common in double-strand conveying), we supply chains in matched pairs to ensure exact alignment and smooth operation.
High-Quality Components: Chain plates are manufactured using fine blanking and ball stamping for high contact rates. Hollow pins are made from seamless precision steel tubes for increased precision and wear resistance. Rollers are case-hardened for durability.

FVC Series Specifications

Specification	Details
Donghua Chain No.	FVC63, FVC90, FVC112, FVC140
Chain Pitch	63 mm, 100 mm, 125 mm (depending on model)
Material	Alloy Steel / Carbon Steel
Construction	Pin, bush, and small roller design
Standards	Based on ISO 606 roller chain dimensions
Key Feature	Hollow pins for attachment mounting
Matching	Available as pair-matched for parallel running
Applications	Conveyor technology, food processing, measuring/testing, feed and automation
Production Capacity	3000 m/month

Key Benefits for Your Application

Benefit	How It Helps Your Operation
Custom Attachment Points	Mount flights, pushers, or carriers exactly where needed without complex brackets or modifications.
Standard Sprocket Compatibility	Use with standard ISO 606 sprockets, reducing inventory complexity and cost.
Precision Pair-Matching	Ensures exact parallel running for double-strand applications, preventing tracking issues and uneven wear.
Durable Construction	Fine-blanked plates, precision tube hollow pins, and case-hardened rollers provide long service life.
Versatile Applications	Suitable for conveyor technology, food processing, automation, and test equipment.

Applications

Our hollow pin conveyor chains are ideal for:

Custom Conveyor Systems: Where product carriers or specialized fixtures need to be attached directly to the chain.
Food Processing: For attaching flights or scrapers in washdown environments (with appropriate materials).
Measuring & Testing Equipment: Where precise positioning and sensor integration is required.
Feed & Automation Technology: For indexing and positioning parts in automated assembly lines.

Why Donghua for Hollow Pin Chain Technology?

Engineering-Focused Approach: We don't just manufacture chains; we provide conveying technology solutions. Our hollow pin chains are designed to give engineers the flexibility to build custom systems without compromising on reliability.
Precision Manufacturing: Using processes like fine blanking, ball stamping, and seamless precision tubing, we ensure every component meets exacting standards for strength and wear resistance.
Pair-Matched Accuracy: For critical applications requiring perfect parallel running, our pair-matching service ensures your double-strand system operates smoothly and with extended life.
Proven Quality: With over 30 years of experience and ISO9001 certification, you can trust our chains to perform in demanding industrial environments.
