Industrial Roller Chains: Conveyor, Agricultural, and Heavy-Duty Series
Donghua manufactures a comprehensive range of industrial chains to meet the demands of conveying, agricultural, and heavy-duty power transmission applications. From standard ANSI roller chains to specialized chains for extreme environments, our products are engineered for durability and performance. As a leading global chain manufacturer since 1991, we provide complete specifications to help you select the right chain for your equipment.
Understanding Our Chain Types
| Chain Category | Description & Applications |
|---|---|
| Heavy Duty Conveyor Chains | Designed for demanding applications like foundries and material handling. Ideal for unstable loads, transfer points, and crossing-over applications. Available in standard and oversized roller versions for reduced friction and better efficiency. |
| Agricultural Chains | Built for farm machinery such as combine harvesters, balers, and feeders. Resistant to dirt and debris. |
| Standard Roller Chains (ANSI/DIN) | For general power transmission and conveying. Available in single, double, and triple strand configurations. |
Model NO.: ca650
Trademark: DONGHUA DP
Specification: pitch 12.7
Origin: Hangzhou zhejiang
HS Code: 7315119000
Key Features for Demanding Applications
Oversized Roller Options: Our chains are available with oversized rollers that extend past the link plates. This reduces friction when the chain slides on a surface, improving efficiency and wear life compared to standard roller chains that require guides.
Self-Lubricating Options: For applications like outdoor foundry conveyors handling hot forgings, we offer chains with self-lubricating features to withstand extreme conditions.
Self-Lubricating Options: For applications like outdoor foundry conveyors handling hot forgings, we offer chains with self-lubricating features to withstand extreme conditions.
Custom Configurations: We can customize roller width, spacing, and chain strength for specific loads (e.g., up to 5,000 lbs per bin) and applications like chain transfer conveyors and load/discharge systems.
OUR PRODUCTS LIST
A and B series single/double/triple standard roller chain and no-standard roller chain
| DIN/ISO | ANSI | Pitch | Roller | Width | Pin | Pin | Lnner | Plate | Ultimate | Average | weight | |
| KIN/ISO | ANSL | between | diameter | length | plate | thick | tensile | tensile | per | |||
| Chain | Chain | inner plates | depth | -ness | strength | strength | meter | |||||
| No. | No. | P | d1 | b1 | d2 | L | Lc | h2 | T | Q | Q0 | q |
| max | min | max | max | max | max | max | min | |||||
| mm | mm | mm | mm | mm | mm | mm | mm | kN/LB | kN | kg/m | ||
| *03C | *15 | 4.7625 | 2.48 | 2.38 | 1.62 | 6.1 | 6.9 | 4.3 | 0.6 | 1.80/409 | 2 | 0.08 |
| *04C-1 | *25 | 6.35 | 3.3 | 3.18 | 2.31 | 7.9 | 8.4 | 6 | 0.8 | 3.50/795 | 4.6 | 0.15 |
| *06C-1 | *35 | 9.525 | 5.08 | 4.77 | 3.58 | 12.4 | 13.17 | 9 | 1.3 | 7.90/1795 | 10.8 | 0.33 |
| 085-1 | 41 | 12.7 | 7.77 | 6.25 | 3.58 | 13.75 | 15 | 9.91 | 1.3 | 6.67/1516 | 12.6 | 0.41 |
| 08A-1 | 40 | 12.7 | 7.95 | 7.85 | 3.96 | 16.6 | 17.8 | 12 | 1.5 | 14.10/3205 | 17.5 | 0.62 |
| 10A-1 | 50 | 15.875 | 10.16 | 9.4 | 5.08 | 20.7 | 22.2 | 15.09 | 2.03 | 22.20/5045 | 29.4 | 1.02 |
| 12A-1 | 60 | 19.05 | 11.91 | 12.57 | 5.94 | 25.9 | 27.7 | 18 | 2.42 | 31.80/7227 | 41.5 | 1.5 |
| 16A-1 | 80 | 25.4 | 15.88 | 15.75 | 7.92 | 32.7 | 35 | 24 | 3.25 | 59.70/12886 | 69.4 | 2.6 |
| 20A-1 | 100 | 31.75 | 19.05 | 18.9 | 9.53 | 40.4 | 44.7 | 30 | 4 | 88.50/20114 | 109.2 | 3.91 |
| 24A-1 | 120 | 38.1 | 22.23 | 25.22 | 11.1 | 50.3 | 54.3 | 35.7 | 4.8 | 127.00/28864 | 156.3 | 5.62 |
| 28A-1 | 140 | 44.45 | 25.4 | 25.22 | 12.7 | 54.4 | 59 | 41 | 5.6 | 172.40/39182 | 212 | 7.5 |
| 32A-1 | 160 | 50.8 | 28.58 | 31.55 | 14.27 | 64.8 | 69.6 | 47.8 | 6.4 | 226.80/51545 | 278.9 | 1.1 |
| 36A-1 | 180 | 57.15 | 35.71 | 35.48 | 17.46 | 72.8 | 78.6 | 53.6 | 7.2 | 280.20/63682 | 341.8 | 13.45 |
| 40A-1 | 200 | 63.5 | 39.68 | 37.85 | 19.85 | 80.3 | 87.2 | 60 | 8 | 353.80/80409 | 431.6 | 16.15 |
| 48A-1 | 240 | 76.2 | 47.63 | 47.35 | 23.81 | 90.5 | 103 | 72.39 | 9.5 | 51.30/115977 | 622.5 | |
Why Donghua for Your Industrial Chains?
Complete Product Range:
From tiny #25 chain to massive 240 series, and from standard conveyor to heavy-duty agricultural, we have the chain you need.
Engineering Expertise:
With decades of experience, we understand the stresses of industrial applications. Our chains are engineered with precise heat treatment and material selection for maximum tensile strength and fatigue resistance.
Global Leader, Reliable Partner:
As one of the world's top chain manufacturers, you can trust our quality, consistency, and supply capacity.
