Designing & Manufacturing Precision Roller Chains for High-Performance Power Transmission
Donghua specializes in the design and manufacturing of precision roller chains-the industry standard for reliable power transmission in industrial machinery, conveyors, and drive systems. Available in A series and B series short pitch configurations, our chains excel in applications requiring high dynamic loads and extended wear life. As a leading global manufacturer since 1991, we deliver precision roller chains engineered for durability and consistent performance.
Precision Roller Chain Technology: Engineered for Durability
Donghua precision roller chains are manufactured with advanced engineering features that ensure exceptional performance:
Wide Waist Design: For 60H and larger chains, the wide waist design enhances strength for demanding applications.
Spheroidized Chain Plate Holes: Chains sizes 80 and larger undergo ball treatment after heat treatment to significantly increase fatigue strength.
Solid Bushings and Rollers: Solid bushings provide extended wear life; solid rollers interact smoothly with sprockets for reduced friction.
Hot Dip Lubrication: Chains come pre-lubricated with hot dip lubrication for improved wear life and immediate readiness.
Multiple Strand Options: Available in single and multiple strands (duplex, triplex) for higher load capacity.
Precision Roller Chain Specifications
| Specification | Available Options / Details |
|---|---|
| Series | A Series short pitch, B Series short pitch |
| Chain Sizes (DIN) | 05B-2, 06B-2, 08B-2, 10B-2, 12B-2, 16B-2, up to 72B-2 |
| Pitch Range | 8 mm to 25.4 mm and above |
| Material | Alloy steel, carbon steel |
| Surface Treatment | Shot peening, blacking, blueing |
| Construction | Roller chain with solid bushings and rollers |
| Strand Options | Single, duplex, triplex, multi-strand |
| Connection Style | Riveted or open style |
| Length Options | 10 ft boxes, 50 ft reels, 100 ft reels, cut-to-length special orders |
| Applications | Industrial machinery, power transmission, conveying systems |
| Certification | ISO9001 |
| Production Capacity | 10,000 m/month |
| MOQ | 50 meters |
Production Process
Our precision roller chains are ideal for:
Industrial Machinery: Power transmission in manufacturing equipment
Conveyor Systems: Material handling and assembly lines
Agricultural Equipment: Harvesters, balers, and farm machinery
Automotive: Assembly line conveyors and drive systems
Packaging Machinery: High-speed packaging equipment
Food Processing: Where reliable, clean operation is required
Product name：Precision roller chain
Product system：A series short pitch B series short pitch
Product grouping：Driving Chains
USES: Transmission Chain
Material: Alloy/Carbon Steel
Color：Bling
Transport Packaging：Carbon Package
Specification：ISO9001
Trademark：DONGHUA dp
DIN Chain No：05b-2 06b-2 08b-2 10b-2 12b-2 16b-2---72b-2
Pitch：8 9.525 12.7 15.875 19.05 25.4.....
Structure (for Chain)：Roller Chain
Minimum order quantity：50M
Port：shanghai
Production：10000m/Month
Customs code：73151190
Surface Treatment: Shot Peening / Blacking / Blueing
Main Application: Idustry machinery
